Getting Sensor Data Into TimescaleDB via Django

Posted by

Rowan Molony

Over 2022-23, while working at Mainstream Renewable Power on an internal web application, I maintained a "data pipeline" that fetches files of sensor data readings from the world's most remote places and transforms them into useful datasets.

These datasets form the basis upon which the construction of renewables (wind turbines or solar panels) on site hinges. I rebuilt the pipeline on top of TimescaleDB, which enabled me to massively reduce the complexity of the system involved.

💥

Don’t know what TimescaleDB is? Read this article.

I reflect on this experience in detail in Struggling to Sync Sensors & Databases. I do not, however, discuss how I adapted Django, a Python web framework, to play nicely with this database. In my case, Django served as the “glue” between web browsers and the database. Specifically, to display a web page, it asks a database for the data it needs to render files that the browser interprets (HTML, CSS, and JavaScript) so it can display a user interface.

Let’s walk through an example project to make these adaptations a bit more concrete.

This tutorial assumes some familiarity with Django or a similar web framework. If you have never used Django, I highly recommend the official tutorial.

If you want to follow along locally, you can set up a developer environment via django-timescaledb-example.

If you have any trouble getting set up, feel free to ask a question at django-timescaledb-example/discussions.

Create a Sensor Data App Using Django

Let’s first run

python manage.py startapp sensor

to create files

sensor
├── __init__.py
├── admin.py
├── apps.py
├── migrations
│   └── __init__.py
├── models.py
├── tests.py
└── views.py

and register the app in core/settings.py.

INSTALLED_APPS = [

    # Builtin
    'django.contrib.admin',
    'django.contrib.auth',
    'django.contrib.contenttypes',
    'django.contrib.sessions',
    'django.contrib.messages',
    'django.contrib.staticfiles',

    # Custom
    'sensor'
]

Create a Homepage

Let’s quickly create a homepage that will be displayed on first opening this web application in a browser.

# sensor/views.py

from django.shortcuts import render


def index(request):
    return render(request, "index.html")

<!--- sensor/templates/index.html -->

<div style="text-align: center">
  <h1>django-timescaledb-example</h1>
</div>

# sensor/urls.py

from django.urls import path

from . import views


app_name = "sensor"


urlpatterns = [
    path('', views.index, name="root"),
]

# core/urls.py

from django.contrib import admin
from django.shortcuts import redirect
from django.urls import include
from django.urls import path


urlpatterns = [
    path('', lambda request: redirect('sensor:root')),

    path('admin/', admin.site.urls),
    path('sensor/', include('sensor.urls')),
]

So now http://localhost:8000 should display index.html. We can build on this index.html to link to other pages.

Create a Data Model for Files

Now, I can adapt sensor/models.py to add a File model to track uploaded files,

# sensor/models.py

class File(models.Model):
    file = models.FileField(upload_to="readings/", blank=False, null=False)
    uploaded_at = models.DateTimeField(auto_now_add=True)
    parsed = models.DateTimeField(blank=False, null=False)
    parse_error = models.TextField(blank=True, null=True)

create its database migration,

python manage.py makemigrations sensor

and roll it out:

python manage.py migrate

Any change to sensor/models.py requires a corresponding database migration!

Handle File Uploads via Browser

Now that we have somewhere to store files of readings, we need to handle file uploads.

Let’s consider only the case where time-series data originates only from text files. How do I copy data from files into TimescaleDB via Django?

The Django documentation covers File Uploads. However, it doesn’t advise on importing file contents to a database. One normally uses Django to add and save new entries to PostgreSQL using input from a browser:

Django sends a web page to a browser containing one or more <form> elements.
Once filled in, these <form> elements are sent back to Django.
Django processes these entries and saves them to the database using the Django ORM.

The key enabler here is the ORM (or “Object Relational Mapper”). It maps a Python class to a database table so that this table’s data is easily accessible from within Python. Without an ORM, one would have to use the SQL language to communicate with the database.

We need to do a bit of work to adapt this workflow to handle file contents.

In a similar manner, I can create a “view” to render HTML to accept browser file uploads:

# sensor/views.py

from django.shortcuts import render
from django.shortcuts import redirect
from django.http import HttpResponse

from .forms import FileForm


# ...


def upload_file(request):
    if request.method == "POST":
        form = FileForm(request.POST, request.FILES)
        if form.is_valid():
            form.save()
            return HttpResponse("File upload was successful")
        else:
            return HttpResponse("File upload failed")
    else:
        form = FileForm()
    return render(request, "upload_file.html", {"form": form})


# ...

# sensor/forms.py

from django.forms import ModelForm

from .models import File


class FileForm(ModelForm):
    class Meta:
        model = File
        fields = "__all__"

<!--- sensor/templates/upload_file.html -->

<div style="text-align: center">
  <h1>Upload File</h1>
  <form enctype="multipart/form-data" method="post">
    {% csrf_token %}
    {% for field in form %}
      <div style="margin-bottom: 10px">
        {{ field.label_tag }}
        {{ field }}
        {% if field.help_text %}
          <span class="question-mark" title="{{ field.help_text }}">&#63;</span>
        {% endif %}
      </div>
    {% endfor %}
    <input type="submit" value="Save"></input>
  </form>
</div>

# sensor/urls.py

from django.urls import path

from . import views


app_name = "sensor"


urlpatterns = [
    path('', views.index, name="root"),
    path('upload-file/', views.upload_file, name="upload-file"),
]

This requires someone to click through this web application every time they want to add new data. If data is synced automatically from remote sensors to a file system somewhere, then why not set up automatic file uploads? For this, we need an API.

An API (or Application Programming Interface) lets our web application accept file uploads from another program.

The django-rest-framework library does a lot of heavy lifting here, so let’s use it.

If you are not interested in APIs, feel free to skip the API sections.

If you have never used django-rest-framework, consider first completing the official tutorial before continuing.

Create an API Homepage

As suggested by Two Scoops of Django 3.x, let’s create core/api_urls.py to wire up our API.

# core/urls.py

from django.contrib import admin
from django.shortcuts import redirect
from django.urls import include
from django.urls import path


urlpatterns = [
    path('', lambda request: redirect('sensor:root')),

    path('admin/', admin.site.urls),
    path('api/', include('core.api_urls')),
    path('sensor/', include('sensor.urls')),
]

# core/api_urls.py

from django.urls import include
from django.urls import path
from rest_framework.decorators import api_view
from rest_framework.response import Response
from rest_framework.reverse import reverse


app_name = "api"


@api_view(['GET'])
def api_root(request, format=None):
    return Response({
        'sensors': reverse('api:sensor:api-root', request=request, format=format),
    })


urlpatterns = [
    path('', api_root, name="api-root"),
    path('sensor/', include('sensor.api_urls'), name='sensor'),
]

# core/api_urls.py

from django.urls import include
from django.urls import path
from rest_framework.decorators import api_view
from rest_framework.response import Response
from rest_framework.reverse import reverse

from .api import viewsets


app_name = "sensor"


@api_view(['GET'])
def api_root(request, format=None):
    return Response({})


urlpatterns = [
    path('', api_root, name="api-root"),
]

So now we can add new views and/or view sets to sensor/api_urls.py. Plus, they will be “connectable” via /api/sensor/.

Handle File Uploads via API

We can use a viewset to create an endpoint like /api/sensor/file/ to which another program can upload files:

# sensor/api/viewsets.py

from rest_framework import viewsets

from ..models import File
from .serializers import FileSerializer


class FileViewSet(viewsets.ReadOnlyModelViewSet):
    queryset = File.objects.all()
    serializer_class = FileSerializer

# sensor/api/serializers.py

from rest_framework import serializers

from ..models import File


class FileSerializer(serializers.ModelSerializer):
    class Meta:
        model = File
        fields = ['__all__']

Create a Data Model for Sensor Data Readings

Let’s add a reading model to store readings:

# sensor/models.py

from django.db import models


# ....


class Reading(models.Model):

    class Meta:
        managed = False

    file = models.ForeignKey(File, on_delete=models.RESTRICT)
    timestamp = models.DateTimeField(blank=False, null=False, primary_key=True)
    sensor_name = models.TextField(blank=False, null=False)
    reading = models.TextField(blank=False, null=False)

This time, we’re using timestamp instead of the default id field as a primary key since row uniqueness can be defined by a composite of file, timestamp, and sensor_name if required.

Don’t we want to store readings in a TimescaleDB hypertable to make them easier to work with? Django won’t automatically create a hypertable (it wasn’t designed to), so we need to do so ourselves. Since we need to customize table creation ourselves rather than let Django do it, we have to set managed to False.

Let’s create a “base” migration,

python manage.py makemigrations sensor --name "sensor_reading"

and manually edit the migration:

# sensor/migrations/0002_sensor_reading.py

import django.db.models.deletion
from django.db import migrations, models


class Migration(migrations.Migration):

    dependencies = [
        ('sensor', '0001_initial')
    ]
    operations = [
        migrations.CreateModel(
            name='Reading',
            fields=[
                ('file', models.ForeignKey(default=None, on_delete=django.db.models.deletion.RESTRICT, to='sensor.file')),
                ('timestamp', models.DateTimeField(primary_key=True)),
                ('sensor_name', models.TextField()),
                ('reading', models.FloatField()),
            ],
            options={
                'managed': False,
            },
        ),
        migrations.RunSQL(
            """
            CREATE TABLE sensor_reading (
                file_id INTEGER NOT NULL REFERENCES sensor_file (id),
                timestamp TIMESTAMP NOT NULL,
                sensor_name TEXT NOT NULL,
                reading FLOAT
            );
            SELECT create_hypertable('sensor_reading', 'timestamp');
            """,
            reverse_sql="""
                DROP TABLE sensor_reading;
            """
        ),
    ]

Now we can roll out migrations,

python manage.py migrate

and connect to the database to inspect the newly created hypertable.

Import Files

Let’s imagine that all of our sensor data readings are stored nicely formatted in JSON files, like:

[
    {
      "reading": 20.54,
      "sensor_name": "M(m/s)",
      "timestamp": "2015-12-22 00:00:00",
    },
    {
      "reading": 211.0,
      "sensor_name": "D(deg)",
      "timestamp": "2015-12-22 00:00:00",
    },
]

How do we import these readings?

We can add a method to File to bring the JSON file into Python and create a new Reading entry for each reading in the file:

# sensor/models.py

from datetime import datetime
from datetime import timezone
from itertools import islice

from django.contrib.postgres.fields import ArrayField
from django.db import models
from django.db import transaction

from .io import validate_datetime_fieldnames_in_lines
from .io import yield_readings_in_narrow_format


# ...


class File(models.Model):

    # ...

    def import_to_db(self):

        # NOTE: assume uploaded file is JSON
        with self.file.open(mode="rb") as f:

            reading_objs = (
                Reading(
                    file=self,
                    timestamp=r["timestamp"],
                    sensor_name=r["sensor_name"],
                    reading=r["reading"]
                )
                for r in json.load(f)
            )

            batch_size = 1_000

            with transaction.atomic():
                while True:
                    batch = list(islice(reading_objs, batch_size))
                    if not batch:
                        break
                    Reading.objects.bulk_create(batch, batch_size)

How do we call the import_to_db method?

We can go about this a few different ways, but perhaps the simplest is just to implement it directly in the views and viewsets so that it will be triggered on browser and API file uploads.

For Django, we can call it directly in our upload-file view like:

if form.is_valid():
    form.save()
    form.instance.import_to_db()

And for django-rest-framework we can override the perform_create method.

class FileViewSet(viewsets.ModelViewSet):

    # ...

    def perform_create(self, serializer):
        instance = serializer.save()
        instance.import_to_db()

Import Files via Celery

What if each file contains a few gigabytes of readings? Won’t this take an age to process?

If you can’t guarantee that the sensor files are small enough to be processed quickly, you might need to offload file importing to a task queue.

A task queue works like a restaurant. The waiters add an order to the queue, and the chefs pull orders from the queue when they have time to process them.

Celery is a mature Python task queue library and works well with Django, so let’s use it. It coordinates “waiters” and “chefs” using the above analogy by leveraging a database (or message broker), typically Redis or RabbitMQ.

A task queue can significantly improve performance here. It makes file uploads instant from the user’s perspective since now file upload tasks are added to a queue rather than running immediately. It also enables parallel processing of files since task queue workers run in parallel to one another.

Celery may not work well on Windows, so consider trying dramatiq instead if this is a hard requirement.

Why not use Postgres as a message broker? The django-q implementation enables this via the Django ORM message broker. This might be a better choice for small-scale applications since it reduces system complexity.

To set up Celery, we can follow their official tutorial:

# core/celery.py

import os

from celery import Celery

# Set the default Django settings module for the 'celery' program.
os.environ.setdefault('DJANGO_SETTINGS_MODULE', 'core.settings')

app = Celery('core')

# Using a string here means the worker doesn't have to serialize
# the configuration object to child processes.
# - namespace='CELERY' means all celery-related configuration keys
#   should have a `CELERY_` prefix.
app.config_from_object('django.conf:settings', namespace='CELERY')

# Load task modules from all registered Django apps.
app.autodiscover_tasks()


@app.task(bind=True, ignore_result=True)
def debug_task(self):
    print(f'Request: {self.request!r}')

# core/settings.py

# ...

CELERY_BROKER_URL = "redis://localhost:6379/0"

So now we can add tasks to sensor/tasks.py like:

# sensor/tasks.py

from celery import shared_task

from .models import File


@shared_task
def import_to_db(file_id):
    file_obj = File.objects.get(id=file_id)
    file_obj.import_to_db()

And replace all calls to <file_obj>.import_to_db() with tasks.import_to_db(file_obj), and this task won’t be run immediately but rather will be run by Celery when it has the availability to do so!

Next Steps?

If you really want to further eke out import performance, you’ll have to go deeper and experiment with the following:

Batch sizes: how many readings do you want to save at once?
Compression: TimescaleDB really shines once hypertables are compressed since it reduces storage costs and delivers faster analytics queries.

We want to thank Rowan Molony for this awesome guest blog post (scroll down for some bonus advice) and for gracefully implementing our team's technical revisions in collaboration with the Timescale developer advocate Jônatas. Join Rowan and thousands of other developers building with TimescaleDB in our Slack community. Once you're there, reach out to Ana if you, too, would like to write a guest blog post.

To try TimescaleDB, you can self-host or create a fully managed Timescale account (it's free for 30 days, no credit card required).

Bonus

Import messy files

How do we convert files like

Lat=0  Lon=0  Hub-Height=160  Timezone=00.0  Terrain-Height=0.0
Computed at 100 m resolution

YYYYMMDD HHMM   M(m/s) D(deg) SD(m/s)  DSD(deg)  Gust3s(m/s)    T(C)    PRE(hPa)       RiNumber  VertM(m/s)
20151222 0000  20.54   211.0    1.22       0.3        21.00     11.9      992.8            0.15    0.18
20151222 0010  21.02   212.2    2.55       0.6        21.35     11.8      992.7            0.29   -0.09

into

[
    {
      'reading': '20.54',
      'sensor_name': 'M(m/s)',
      'timestamp': datetime.datetime(2015, 12, 22, 0, 0),
    },
    {
      'reading': '211.0',
      'sensor_name': 'D(deg)',
      'timestamp': datetime.datetime(2015, 12, 22, 0, 0),
    },
    # ...
]

so we can store them in the Reading data model?

In this file, YYYYMMDD and HHMM clearly represent the timestamp, so 20151222 0000 corresponds to datetime.datetime(2015, 12, 22, 0, 0). However, this may differ between sources.

One way to generalize the importer is to upload a FileType specification alongside each file so we know how to standardize it.

We can create a new model FileType and link it to File like:

# sensor/models.py

from django.contrib.postgres.fields import ArrayField
from django.db import models


class FileType(models.Model):

    name = models.TextField()
    na_values = ArrayField(
        base_field=models.CharField(max_length=10),
        default=["NaN"],
        help_text=textwrap.dedent(
            r"""A list of strings to recognise as empty values.

            Default: ["NaN"]

            Note: "" is also included by default

            Example: ["NAN", "-9999", "-9999.0"]
            """
        ),
    )
    delimiter = models.CharField(
        max_length=5,
        help_text=textwrap.dedent(
            r"""The character used to separate fields in the file.

            Default: ","

            Examples: "," or ";" or "\s+" for whitespace or "\t" for tabs
            """
        ),
        default=",",
    )
    datetime_fieldnames = ArrayField(
        base_field=models.CharField(max_length=50),
        default=["Time"],
        help_text=textwrap.dedent(
            r"""A list of datetime field names.

            Examples:

            1) Data has a single datetime field named "Time" which has values like
            '2021-06-29 00:00:00.000':  ["Time"]

            2) Data has two datetime fields named "Date" and "Time" which have values
            like '01.01.1999' and '00:00' respectively: ["Date","Time"]
            """
        ),
    )
    encoding = models.CharField(
        max_length=25,
        help_text=textwrap.dedent(
            r"""The encoding of the file.

            Default: "utf-8"

            Examples: utf-8 or latin-1 or cp1252
            """
        ),
        default="utf-8",
    )
    datetime_formats = ArrayField(
        base_field=models.CharField(max_length=25),
        help_text=textwrap.dedent(
            r"""The datetime format of `datetime_columns`.

            See https://docs.python.org/3/library/datetime.html#strftime-and-strptime-format-codes
            for format codes

            Default: "%Y-%m-%d %H:%M:%S"

            Examples: "%Y-%m-%d %H:%M:%S" for "2021-03-01 00:00:00"
            """
        ),
        default=[r"%Y-%m-%d %H:%M:%S"],
    )


class File(models.Model):

    # ...
    type = models.ForeignKey(FileType, on_delete=models.RESTRICT)

Django forms are smart enough to automatically render the upload-file view with a type field since we specified fields = "__all__" in sensor/forms.py.

django-rest-framework viewsets will also include it, thanks to fields = "__all__" in sensor/api/serializers.py. However, its default behavior for foreign keys is not ideal. It expects to receive a numeric ID for field type, whereas it’s more intuitive to specify the name field instead.

We can easily override this default behavior by specifying SlugRelatedField in our serializer:

# sensor/api/serializers.py

from rest_framework import serializers

from ..models import File
from ..models import FileType


class FileSerializer(serializers.ModelSerializer):

    type = serializers.SlugRelatedField(
        slug_field="name", queryset=FileType.objects.all()
    )

    class Meta:
        model = File
        fields = '__all__'

so we can create files by passing the endpoint a payload like:

{
    "file": "file",
    "type": "name-of-file-type",
}

Now we have all of the information we need to extract time series from files into our data model.

Validate messy files

What if a File is created with an inappropriate FileType? How do we catch this before it causes importing to fail?

We can implement a clean method on File! Django will automatically call this method on running form.is_valid() in our view; however, we’ll have to connect django-rest-framework ourselves. We can just add a validate method to our serializer to achieve the same behavior.

# sensor/api/serializers.py

from rest_framework import serializers

from ..models import File
from ..models import FileType


class FileSerializer(serializers.ModelSerializer):

    # ...

    def validate(self, attrs):
        instance = File(**attrs)
        instance.clean()
        return attrs

Now, we can implement the clean method to check file contents prior to saving a file:

# sensor/models.py

from django.db import models
from django.core.exceptions import ValidationError

from .io import validate_datetime_fieldnames_in_lines

# ...

class File(models.Model):

    # ...

    def clean(self):

        if self.type is None:
            raise ValidationError("File type must be specified!")

        # NOTE: This file is automatically closed upon saving a model instance
        # ... each time a file is read the file pointer must be reset to enable rereads
        f = self.file.open(mode="rb")

        # NOTE: automatically called by Django Forms & DRF Serializer Validate Method
        validate_datetime_fieldnames_in_lines(
            lines=f,
            encoding=self.type.encoding,
            delimiter=self.type.delimiter,
            datetime_fieldnames=self.type.datetime_fieldnames,
        )
        self.file.seek(0)


# ...

# sensor/io.py

import re
import typing

from django.core.exceptions import ValidationError


def yield_split_lines(
    lines: typing.Iterable[bytes],
    encoding: str,
    delimiter: str,
) -> typing.Iterator[typing.Tuple[typing.Any]]:

    # Unescape strings `\\t` to `\t` for use in a regular expression
    # https://stackoverflow.com/questions/1885181/how-to-un-escape-a-backslash-escaped-string
    unescape_backslash = lambda s: (
        s.encode('raw_unicode_escape').decode('unicode_escape')
    )
    split = lambda s: re.split(unescape_backslash(delimiter), s)
    return (split(line.decode(encoding)) for line in iter(lines))


def validate_datetime_fieldnames_in_lines(
    lines: typing.Iterable[bytes],
    encoding: str,
    delimiter: str,
    datetime_fieldnames: typing.Iterable[str],
) -> None:

    split_lines = yield_split_lines(lines=lines, encoding=encoding, delimiter=delimiter)
    fieldnames = None

    for line in split_lines:
        if set(datetime_fieldnames).issubset(set(line)):
            fieldnames = line
            break

    if fieldnames == None:
        raise ValidationError(f"No `datetime_fieldnames` {datetime_fieldnames} found!")

Import and validate messy files

Now we have everything we need to import files:

# sensor/models.py

from itertools import islice

from django.db import models
from django.db import transaction

from .io import validate_datetime_fieldnames_in_lines
from .io import yield_readings_in_narrow_format


# ...


class File(models.Model):

    # ...

    def import_to_db(self):

        with self.file.open(mode="rb") as f:

            reading_objs = (
                Reading(
                    file=self,
                    timestamp=r["timestamp"],
                    sensor_name=r["sensor_name"],
                    reading=r["reading"]
                )
                for r in yield_readings_in_narrow_format(
                    lines=f,
                    encoding=self.type.encoding,
                    delimiter=self.type.delimiter,
                    datetime_fieldnames=self.type.datetime_fieldnames,
                    datetime_formats=self.type.datetime_formats,
                )
            )

            batch_size = 1_000
        try:
                with transaction.atomic():
                    while True:
                        batch = list(islice(reading_objs, batch_size))
                        if not batch:
                            break
                        Reading.objects.bulk_create(batch, batch_size)

            except Exception as e:
                self.parsed_at = None
                self.parse_error = str(e)
                self.save()
                raise e

            else:
                self.parsed_at = datetime.now(timezone.utc)
                self.parse_error = None
                self.save()

# sensor/io.py

from collections import OrderedDict
from datetime import datetime
import re
import typing

from django.core.exceptions import ValidationError


# ...


def yield_readings_in_narrow_format(
    lines: typing.Iterable[bytes],
    encoding: str,
    delimiter: str,
    datetime_fieldnames: typing.Iterable[str],
    datetime_formats: typing.Iterable[str],
) -> typing.Iterator[typing.Tuple[typing.Any]]:
    """
    https://en.wikipedia.org/wiki/Wide_and_narrow_data
    """

    split_lines = yield_split_lines(lines=lines, encoding=encoding, delimiter=delimiter)
    fieldnames = None

    for line in split_lines:
        if set(datetime_fieldnames).issubset(set(line)):
            fieldnames = line
            break

    if fieldnames == None:
        raise ValidationError(f"No `datetime_fieldnames` {datetime_fieldnames} found!")

    # NOTE: `split_lines` is an iterator so prior loop exhausts the header lines
    for line in split_lines:
        fields = OrderedDict([(f, v) for f, v in zip(fieldnames, line)])
        readings = OrderedDict(
            [(f, v) for f, v in fields.items() if f not in datetime_fieldnames]
        )

        timestamp_strs = [fields[k] for k in datetime_fieldnames]
        timestamp_str = " ".join(
            str(item) for item in timestamp_strs if item is not None
        )

        for datetime_format in datetime_formats:
            try:
                timestamp = datetime.strptime(timestamp_str, datetime_format)
            except ValueError:
                pass
            else:
                for sensor, reading in readings.items():
                    yield {
                        "timestamp": timestamp,
                        "sensor_name": sensor,
                        "reading": reading,
                    }

Once again, let’s adapt the views and viewsets to call the import_to_db method.

For Django, we can call it directly in our upload-file view like

if form.is_valid():
    form.save()
    form.instance.import_to_db()

and for django-rest-framework we can override the perform_create method:

class FileViewSet(viewsets.ModelViewSet):

    # ...

    def perform_create(self, serializer):
        instance = serializer.save()
        instance.import_to_db()

Date published

Jan 19, 2024

Posted by

Rowan Molony

Date published

Jan 19, 2024

Posted by

Rowan Molony
